Approx.
Excavator Weight (Ton) |
Full Open(A.mm) |
Full Closed(B.mm) |
Height Closed(C.mm) |
Width Upper Moveable Jaw |
Width Lower Fixed Jaw |
Weight(Ton) |
| HGR10 |
10~15 |
2200 |
230 |
1330 |
640 |
1000 |
780 |
| MGR10 |
|
|
|
|
710 |
1000 |
820 |
| HGR20 |
15~20 |
2600 |
250 |
1460 |
730 |
1140 |
1330 |
| MGR20 |
|
|
|
|
810 |
1140 |
1400 |
| HGR30 |
20~25 |
2900 |
260 |
1580 |
730 |
1140 |
1560 |
| MGR30 |
|
|
|
|
810 |
1140 |
1640 |
| HGR40 |
25~30 |
3100 |
280 |
1700 |
800 |
1240 |
1980 |
| MGR40 |
|
|
|
|
880 |
1240 |
2080 |
| HGR50 |
30~40 |
3250 |
310 |
1810 |
840 |
1338 |
2450 |
| MGR50 |
|
|
|
|
950 |
1338 |
2560 |
| HGR60 |
40~50 |
3500 |
330 |
1970 |
960 |
1520 |
2990 |
| MGR60 |
|
|
|
|
1080 |
1520 |
3110 |
|
|
|
|
|
|
